Performance Material · Pure Nickel & Nickel-Base Alloys
Niclal 400
NiCu32Fe2Mn · UNS N04400
Niclal 400: Pure Nickel & Nickel-Base Alloys from the Lebronze Alloys North American range.
DIN 17743 W n°2.4360
✓ Lead-free · REACH / RoHSOverview
Pure Nickel & Nickel-Base Alloys.
Niclal 400: Pure Nickel & Nickel-Base Alloys from the Lebronze Alloys North American range.
Sectors served
FamilyPure Nickel & Nickel-Base Alloys
CompositionNiCu32Fe2Mn
UNSN04400
Density8.8 g/cm³
Conductivity7.5 %IACS
FormsStrips
Mechanical properties
Minimum guaranteed properties.
Minimum guaranteed values by grade and product form.
| Grade / spec | Form | Tensile (ksi) | Yield 0.2% (ksi) | Elong. (%) | Hardness (HB) | Hardness (HRC) | Compliant with |
|---|---|---|---|---|---|---|---|
| As supplied | Strips | 78 ksi | 26 ksi | 35 | 137 | n/a | DIN 17743 W n°2.4360 |
Data for information only, non-contractual. Request a certified datasheet for design allowables.
Physical properties
| Density | 8.8 g/cm³ |
| Electrical conductivity | 7.5 %IACS |
| Thermal conductivity | 22 W/m·K |
| Young's modulus | 179 GPa |
| Thermal expansion | 13.9 ×10⁻⁶/K |
| Magnetic permeability | n/a |
| Machinability index | n/a |
| NACE corrosion rating | n/a |
Standards & specifications
Norms & designations.
Norms & designations
- DIN 17743 W n°2.4360
Available forms
Forms & applications.
Available form
Strips
Industries using Niclal 400
