Performance Material · Pure Nickel & Nickel-Base Alloys
Nickel 201
NiMnSiC · UNS N02201
Nickel 201: Pure Nickel & Nickel-Base Alloys from the Lebronze Alloys North American range.
DIN 17740 W n°2.4068
✓ Lead-free · REACH / RoHSOverview
Pure Nickel & Nickel-Base Alloys.
Nickel 201: Pure Nickel & Nickel-Base Alloys from the Lebronze Alloys North American range.
Sectors served
FamilyPure Nickel & Nickel-Base Alloys
CompositionNiMnSiC
UNSN02201
Temper0
Density8.9 g/cm³
Conductivity18 %IACS
FormsStrips
Mechanical properties
Minimum guaranteed properties.
Minimum guaranteed values by grade and product form.
| Grade / spec | Form | Tensile (ksi) | Yield 0.2% (ksi) | Elong. (%) | Hardness (HB) | Hardness (HRC) | Compliant with |
|---|---|---|---|---|---|---|---|
| 0 | Strips | 55 ksi | 14 ksi | 40 | 103 | n/a | DIN 17740 W n°2.4068 |
Data for information only, non-contractual. Request a certified datasheet for design allowables.
Physical properties
| Density | 8.9 g/cm³ |
| Electrical conductivity | 18 %IACS |
| Thermal conductivity | 79.2 W/m·K |
| Young's modulus | 204 GPa |
| Thermal expansion | 13.3 ×10⁻⁶/K |
| Magnetic permeability | n/a |
| Machinability index | n/a |
| NACE corrosion rating | 5 |
Standards & specifications
Norms & designations.
Norms & designations
- DIN 17740 W n°2.4068
Available forms
Forms & applications.
Available form
Strips
Industries using Nickel 201
