Performance Material · Pure Nickel & Nickel-Base Alloys
Nickel 206C
NiMnSiC
Nickel 206C: Pure Nickel & Nickel-Base Alloys from the Lebronze Alloys North American range.
DIN 17740 W n°2.4061
✓ Lead-free · REACH / RoHSOverview
Pure Nickel & Nickel-Base Alloys.
Nickel 206C: Pure Nickel & Nickel-Base Alloys from the Lebronze Alloys North American range.
Sectors served
FamilyPure Nickel & Nickel-Base Alloys
CompositionNiMnSiC
Density8.9 g/cm³
Conductivity20.7 %IACS
FormsStrips
Mechanical properties
Minimum guaranteed properties.
Minimum guaranteed values by grade and product form.
| Grade / spec | Form | Tensile (ksi) | Yield 0.2% (ksi) | Elong. (%) | Hardness (HB) | Hardness (HRC) | Compliant with |
|---|---|---|---|---|---|---|---|
| As supplied | Strips | 51 ksi | 16 ksi | 40 | 103 | n/a | DIN 17740 W n°2.4061 |
Data for information only, non-contractual. Request a certified datasheet for design allowables.
Physical properties
| Density | 8.9 g/cm³ |
| Electrical conductivity | 20.7 %IACS |
| Thermal conductivity | 70 W/m·K |
| Young's modulus | 204 GPa |
| Thermal expansion | 13.3 ×10⁻⁶/K |
| Magnetic permeability | n/a |
| Machinability index | n/a |
| NACE corrosion rating | 5 |
Standards & specifications
Norms & designations.
Norms & designations
- DIN 17740 W n°2.4061
Available forms
Forms & applications.
Available form
Strips
Industries using Nickel 206C
