Performance Material · Nickel Silvers
ARCAP AP1
Cu64Ni25Zn11
ARCAP AP1: Nickel Silvers from the Lebronze Alloys North American range.
✓ Lead-free · REACH / RoHSOverview
Nickel Silvers.
ARCAP AP1: Nickel Silvers from the Lebronze Alloys North American range.
Sectors served
FamilyNickel Silvers
CompositionCu64Ni25Zn11
Temper0
Density8.8 g/cm³
Conductivity4.3 %IACS
FormsStrips
Mechanical properties
Minimum guaranteed properties.
Minimum guaranteed values by grade and product form.
| Grade / spec | Form | Tensile (ksi) | Yield 0.2% (ksi) | Elong. (%) | Hardness (HB) | Hardness (HRC) | Compliant with |
|---|---|---|---|---|---|---|---|
| 0 | Strips | 61 ksi | 44 ksi | 30 | 127 | n/a | — |
Data for information only, non-contractual. Request a certified datasheet for design allowables.
Physical properties
| Density | 8.8 g/cm³ |
| Electrical conductivity | 4.3 %IACS |
| Thermal conductivity | 22 W/m·K |
| Young's modulus | 163 GPa |
| Thermal expansion | 16 ×10⁻⁶/K |
| Magnetic permeability | n/a |
| Machinability index | n/a |
| NACE corrosion rating | n/a |
Available forms
Forms & applications.
Available form
Strips
Industries using ARCAP AP1
