Niclafor 1000
A range of high-performance spinodal copper-nickel-tin alloys (CuNi9Sn6) with tensile and yield strength above 1,000 MPa (145 ksi) depending on temper, excellent fatigue resistance and low friction, and a beryllium-free substitute for beryllium copper (C17200) and copper-titanium.
✓ Beryllium-free · Lead-free · Cadmium-free · REACH / RoHSVery high strength
Tensile & yield above 1,000 MPa (145 ksi) depending on temper, even at high temperature.
Excellent fatigue resistance
Outstanding fatigue life under demanding cyclic loading.
Low friction & wear
Low friction, ideal for bushings and bearings in high-performance engines.
Conductive & EMC
High conductivity and good electromagnetic shielding effectiveness.
BeCu / CuTi substitute
Beryllium-free substitute for beryllium copper (C17200) and copper-titanium.
Fully integrated supply
Cast to finished form in-house, full traceability.
Copper-Nickel-Tin Alloys.
Niclafor® 1000 is a range of spinodal copper-nickel-tin alloys (CuNi9Sn6, UNS C72700) designed for high-performance applications. Solution annealing, work hardening and spinodal hardening deliver very high mechanical properties, tensile and yield strength above 1,000 MPa (145 ksi) depending on temper, retained even at elevated temperature.
With excellent fatigue resistance, low friction, high conductivity, very good corrosion resistance and good electromagnetic shielding, Niclafor® 1000 is a beryllium-free substitute for beryllium copper (C17200) and copper-titanium.
Beryllium-, lead- and cadmium-free and REACH / RoHS compliant, it is produced in-house from casting through to finished form with full traceability.
Minimum guaranteed properties.
| Grade / spec | Form | Tensile (ksi) | Yield 0.2% (ksi) | Elong. (%) | Hardness (HB) | Hardness (HRC) | Compliant with |
|---|---|---|---|---|---|---|---|
| TDX | Rods | 128 ksi | 116 ksi | 0.1 | 240 | 23 | ASTM B740 |
| THX | Rods | 170 ksi | 160 ksi | 0.5 | 331 | 36 | ASTM B740 |
| TD4 | Strips | 102 ksi | 87 ksi | 1 | 212 | 18 | ASTM B740 |
| TH4 | Strips | 145 ksi | 131 ksi | 3 | 314 | 34 | ASTM B740 |
| TB | Wires | 58 ksi | 29 ksi | 30 | 149 | n/a | ASTM B740 |
| TD4 | Wires | 113 ksi | 102 ksi | 1.5 | 230 | 22 | ASTM B740 |
| TH4 | Wires | 160 ksi | 145 ksi | 2 | 314 | 34 | ASTM B740 |
Data for information only, non-contractual. Request a certified datasheet for design allowables.
Physical properties
| Density | 8.9 g/cm³ |
| Electrical conductivity | 9 %IACS |
| Thermal conductivity | 53.6 W/m·K |
| Young's modulus | 120 GPa |
| Thermal expansion | 17.25 ×10⁻⁶/K |
| Magnetic permeability | 1.01 |
| Machinability index | n/a |
| NACE corrosion rating | 4 |
Norms & designations.
Standards
- ASTM B740
- UNS C72700 / C727
- EN CW355H
Substitutes
- Beryllium copper C17200 (CuBe2)
- Copper-titanium (CuTi)
Forms & applications.
Strip, sheet & plate
Strip in coils, sheet and plate for formed contacts, springs, fingerstock and shielding.
Rods & wires
Drawn rod and wire, 1 mm < Ø ≤ 15 mm (0.04″–0.59″), across the TDX / THX / TD4 / TH4 tempers.
Special profiles
Custom extruded and drawn profiles to drawing.
Connectors & contacts
Connectors, relays, fingerstock, test probes and contacts for electronics and aerospace systems.
Engine bushings & bearings
Bushings and bearings for high-performance engines, excellent fatigue resistance and low friction.
Mobile & telecom
Telecom, mobile phones and appliances requiring high elasticity and conductivity.
Watches & eyewear
High-elasticity, formable micro components for watches and eyewear.
Conductive hardware
Electrical-engineering parts requiring strength and conductivity.
High-strength performance, beryllium-free.
Niclafor® 1000 substitutes beryllium copper (C17200) and copper-titanium across strip, sheet and wire formats. Send your spec and we will map it to the right Niclafor temper.
