Performance Material · Nickel Silvers
ARCAP AP1D
CuNi25Zn11.5Pb1 · UNS C79350
ARCAP AP1D: Nickel Silvers from the Lebronze Alloys North American range.
Overview
Nickel Silvers.
ARCAP AP1D: Nickel Silvers from the Lebronze Alloys North American range.
Sectors served
FamilyNickel Silvers
CompositionCuNi25Zn11.5Pb1
UNSC79350
TemperH14
Density8.8 g/cm³
Conductivity4 %IACS
MagneticNo
FormsRods
Mechanical properties
Minimum guaranteed properties.
Minimum guaranteed values by grade and product form.
| Grade / spec | Form | Tensile (ksi) | Yield 0.2% (ksi) | Elong. (%) | Hardness (HB) | Hardness (HRC) | Compliant with |
|---|---|---|---|---|---|---|---|
| H14 | Rods | 87 ksi | 87 ksi | 2 | 160 | 3 | — |
Data for information only, non-contractual. Request a certified datasheet for design allowables.
Physical properties
| Density | 8.8 g/cm³ |
| Electrical conductivity | 4 %IACS |
| Thermal conductivity | 22 W/m·K |
| Young's modulus | 163 GPa |
| Thermal expansion | 16 ×10⁻⁶/K |
| Magnetic permeability | 1.002 |
| Machinability index | 80 |
| NACE corrosion rating | 5 |
Available forms
Forms & applications.
Available form
Rods
Industries using ARCAP AP1D
