Performance Material · Pure & Low-Alloyed Copper
CRM16
CuCr1Zr · UNS C18100 | C18150
CRM16: Pure & Low-Alloyed Copper from the Lebronze Alloys North American range.
CW106CCA184CC102BS2874
✓ Lead-free · REACH / RoHSOverview
Pure & Low-Alloyed Copper.
CRM16: Pure & Low-Alloyed Copper from the Lebronze Alloys North American range.
Sectors served
FamilyPure & Low-Alloyed Copper
CompositionCuCr1Zr
UNSC18100 | C18150
TempersTER / TR
Density8.9 g/cm³
Conductivity75 %IACS
MagneticNo
FormsBars
Mechanical properties
Minimum guaranteed properties.
Minimum guaranteed values by grade and product form.
| Grade / spec | Form | Tensile (ksi) | Yield 0.2% (ksi) | Elong. (%) | Hardness (HB) | Hardness (HRC) | Compliant with |
|---|---|---|---|---|---|---|---|
| CRM16 TER | Bars | 64 ksi | 52 ksi | 18 | 140 | n/a | CA184, CC102, CW106C, BS2874 |
| CRM16 TR | Bars | 51 ksi | 35 ksi | 20 | 120 | n/a | CA184, CC102, CW106C, BS2874 |
Data for information only, non-contractual. Request a certified datasheet for design allowables.
Physical properties
| Density | 8.9 g/cm³ |
| Electrical conductivity | 75 %IACS |
| Thermal conductivity | 320 W/m·K |
| Young's modulus | 120 GPa |
| Thermal expansion | 17.5 ×10⁻⁶/K |
| Magnetic permeability | 1.01 |
| Machinability index | 20 |
| NACE corrosion rating | n/a |
Standards & specifications
Norms & designations.
Norms & designations
- CW106C
- CA184
- CC102
- BS2874
Available forms
Forms & applications.
Available form
Bars
Industries using CRM16
