Performance Material · Copper-Nickel Alloys

Navinic 10

CuNi10Fe1Mn · UNS C70600 | C70610 | C70620 | 7060X

Navinic 10: Copper-Nickel Alloys from the Lebronze Alloys North American range.

ASTM B466EEMUA 234BS 2871BS 2874CN 102
Request a quote
Request a sample →Talk to an expert →
Navinic 10✓ Lead-free · REACH / RoHS
Overview

Copper-Nickel Alloys.

Navinic 10: Copper-Nickel Alloys from the Lebronze Alloys North American range.

Sectors served
Energy / Oil & GasDefense & Marine
FamilyCopper-Nickel Alloys
CompositionCuNi10Fe1Mn
UNSC70600 | C70610 | C70620 | 7060X
TempersAnnealed / Cold worked
Density8.9 g/cm³
Conductivity9 %IACS
MagneticNo
FormsBars, Tubes
Mechanical properties

Minimum guaranteed properties.

Minimum guaranteed values by grade and product form.
Grade / specFormTensile (ksi)Yield 0.2% (ksi)Elong. (%)Hardness (HB)Hardness (HRC)Compliant with
Navinic 10 - AnnealedBars44 ksi16 ksi3570n/aEEMUA 234, BS 2871, BS 2874, CN 102, ASTM B466
Navinic 10 - Cold workedBars51 ksi36 ksi15100n/aEEMUA 234, BS 2871, BS 2874, CN 102, ASTM B466
Navinic 10 - AnnealedTubes44 ksi16 ksi3570n/aEEMUA 234, BS 2871, BS 2874, CN 102, ASTM B466

Data for information only, non-contractual. Request a certified datasheet for design allowables.

Physical properties

Density8.9 g/cm³
Electrical conductivity9 %IACS
Thermal conductivity50 W/m·K
Young's modulus130 GPa
Thermal expansion17 ×10⁻⁶/K
Magnetic permeability1.01
Machinability index20
NACE corrosion rating5
Standards & specifications

Norms & designations.

Norms & designations

  • ASTM B466
  • EEMUA 234
  • BS 2871
  • BS 2874
  • CN 102
Available forms

Forms & applications.

Available form

Bars

Available form

Tubes

Industries using Navinic 10
Energy / Oil & Gas →Defense & Marine →
