Performance Material · Copper-Nickel Alloys

Navinic 30

CuNi30Mn1Fe · UNS C71500 | C71520

Navinic 30: Copper-Nickel Alloys from the Lebronze Alloys North American range.

ASTM B466ASTM B171BS 2871BS 2874MIL C 15726
Request a quote
Request a sample →Talk to an expert →
Navinic 30✓ Lead-free · REACH / RoHS
Overview

Copper-Nickel Alloys.

Navinic 30: Copper-Nickel Alloys from the Lebronze Alloys North American range.

Sectors served
Energy / Oil & GasDefense & Marine
FamilyCopper-Nickel Alloys
CompositionCuNi30Mn1Fe
UNSC71500 | C71520
TempersAnnealed / Cold worked
Density8.9 g/cm³
Conductivity5 %IACS
MagneticNo
FormsBars, Tubes
Mechanical properties

Minimum guaranteed properties.

Minimum guaranteed values by grade and product form.
Grade / specFormTensile (ksi)Yield 0.2% (ksi)Elong. (%)Hardness (HB)Hardness (HRC)Compliant with
Navinic 30 - AnnealedBars51 ksi19 ksi3080n/aBS 2871, BS 2874, ASTM B466, ASTM B171, MIL C 15726
Navinic 30 - Cold workedBars65 ksi44 ksi15120n/aBS 2871, BS 2874, ASTM B466, ASTM B171, MIL C 15726
Navinic 30 - AnnealedTubes51 ksi19 ksi3080n/aBS 2871, BS 2874, ASTM B466, ASTM B171, MIL C 15726

Data for information only, non-contractual. Request a certified datasheet for design allowables.

Physical properties

Density8.9 g/cm³
Electrical conductivity5 %IACS
Thermal conductivity30 W/m·K
Young's modulus130 GPa
Thermal expansion16 ×10⁻⁶/K
Magnetic permeability1.01
Machinability index20
NACE corrosion rating5
Standards & specifications

Norms & designations.

Norms & designations

  • ASTM B466
  • ASTM B171
  • BS 2871
  • BS 2874
  • MIL C 15726
Available forms

Forms & applications.

Available form

Bars

Available form

Tubes

Industries using Navinic 30
Energy / Oil & Gas →Defense & Marine →
